UL4478 Halogen Free XLPE Flat Ribbon Cable Grey PH2.0 PH2.54

Name: UL4478 Halogen Free XLPE Flat Ribbon Cable Grey PH2.0 PH2.54
Brand: XSD Cable
SKU: Single Conductor Wire
Rating: 4.7 (145 reviews)

Product Details

Place of Origin: Guangdong,China

Brand Name: XSD Cable

Certification: UL,CE,ISO:9001

Model Number: Single Conductor Wire

Payment & Shipping Terms

Minimum Order Quantity: 3050Meters

Price: Negotiate

Packaging Details: 31*31*15CM

Delivery Time: 7-14days

Payment Terms: T/T

Supply Ability: 1000000Meter/month

Get Best Price

Product Details

Product Description

Highlight:

Insulation Material:	XLPE	Rated Temperature:	105°C
Conductor:	Tinned Or Bare, Stranded Or Solid Copper	Ul Style:	4478
Application:	For Internal Wiring Of Electronic And Electrical Equipment And Appliance.	Rated Voltage:	300V

Insulation Material:	XLPE
Rated Temperature:	105°C
Conductor:	Tinned Or Bare, Stranded Or Solid Copper
Ul Style:	4478
Application:	For Internal Wiring Of Electronic And Electrical Equipment And Appliance.
Rated Voltage:	300V

UL4478 Halogen Free XLPE Flat Ribbon Cable Grey PH2.0 PH2.54

Product Description:

UL4478 Halogen Free XLPE Flat Ribbon Cable Grey PH2.0 PH2.54
Rated Voltage: 300V
Rated Temperature: 105ºC
Insulation Material: XLPE
Conductor: Tinned or Bare, Stranded or Solid Copper
Reference Standard: UL758, UL1581, C22.2 No.210
Passes UL VW-1 & CSA FT1 vertical flame test.
Uniform insulation thickness of wire to ensure easy stripping and cutting.
For internal wiring of electronic and electrical equipment and appliance.

Technical Parameters:

Conductor			Insulation		Max. Cond. Resistance at 20°C (Ω/km)
AWG	Construction (No./mm)	Diameter (mm)	Nom. Thickness (mm)	Diameter (mm)	Max. Cond. Resistance at 20°C (Ω/km)
2	28	7/0.127	0.23	0.90x1.90	239
10	28	7/0.127	0.23	0.90x12.33	239
14	28	7/0.127	0.23	0.90x17.41	239
16	28	7/0.127	0.23	0.90x19.95	239
3	26	7/0.16	0.23	0.95x6.00	150
4	26	7/0.16	0.23	0.95x7.00	150
8	26	7/0.16	0.23	0.95x12.00	150
10	26	7/0.16	0.23	0.95x20.00	150
※The above datasheet is for reference only, please refer to the final specification.

FAQ:

Q:Is the quality of your product guaranteed?
A:Yes, our workshop are equipped with Brand-new and Advanced Machines and Test Equipment. Our production process and quality are in strictly accordance with the international standards and customers’ requirements. We are warmly welcome your inspection team to examine.
Q:How could I pay?
A:We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q:Can I get a free sample?
A:Yes, we can provide the existing item’s sample without charge but freight collected. If there is any special samples requirement, please contact us for more details.
Q:Are you a manufacturer?
A:Yes, we are a manufacturer located in Dongguan city of China. We can provide OEM/ODM services for customers around the world.
