Awm 1032 90º C 1000V/1200V Electric Wire and Cable Lead Wire Single Conductor Wire with UL Certificate

Name: Awm 1032 90º C 1000V/1200V Electric Wire and Cable Lead Wire Single Conductor Wire with UL Certificate
Brand: XSD Cable
SKU: Single Conductor Wire
Rating: 4.9 (178 reviews)

Product Details

Place of Origin: Guangdong,China

Brand Name: XSD Cable

Certification: UL,CE,ISO:9001

Model Number: Single Conductor Wire

Payment & Shipping Terms

Minimum Order Quantity: 3050Meters

Price: Negotiate

Packaging Details: 31*31*15CM

Delivery Time: 7-30days

Payment Terms: T/T

Supply Ability: 1000000Meter/month

Get Best Price

Product Details

Product Description

Highlight:

Range Of Application:	Electronic And Electrical Equipment And Appliance	Rated Temperature:	90°C
Rating Voltage:	1000V/1200V	Flame Test:	VW-1 & FT1
Standard:	UL758, UL1581, CSA C22.2 No.210	Transport Package:	Rolls Or As Required

Range Of Application:	Electronic And Electrical Equipment And Appliance
Rated Temperature:	90°C
Rating Voltage:	1000V/1200V
Flame Test:	VW-1 & FT1
Standard:	UL758, UL1581, CSA C22.2 No.210
Transport Package:	Rolls Or As Required

Awm 1032 90º C 1000V/1200V Electric Wire and Cable Lead Wire Single Conductor Wire with UL Certificate

Product Description:

AWM 1032 90ºC 1000V/1200V Electric Wire and Cable Lead Wire Single Conductor Wire with UL Certificate
-Rated temperature: 90ºC
-Rated voltage: 1000V/1200V
-Reference Standard: UL758, UL1581, C22.2 No.210
-Passes UL VW-1 & CSA FT1 vertical flame test.
-Uniform insulation thickness of wire to ensure easy stripping and cutting.
-For internal wiring of electronic and electrical equipment and appliance.

Awm 1032 90º C 1000V/1200V Electric Wire and Cable Lead Wire Single Conductor Wire with UL Certificate

Technical Parameters:

Attribute	Value
Product Name	Single Conductor Wire
Ul Certification	2468
Application	General Purpose
Rated Temperature	80°C
Stranding	Solid
Ul Style	2468
Color	Black
Conductor Strand	Solid
Conductor Size	18 AWG
Conductor	Copper
Temperature Rating	90°C

Conductor			Insulation		Max. Cond Resistance at 20°C (Ω/km)
AWG	Construction (No./mm)	Diameter (mm)	Thickness (mm)	Diameter (mm)	Max. Cond Resistance at 20°C (Ω/km)
26	7/0.16	0.48	0.26	1.00	150
24	7/0.20	0.60	0.26	1.12	94.2
22	17/0.16	0.76	0.26	1.28	59.4
20	26/0.16	0.94	0.26	1.46	36.7
18	16/0.254	1.18	0.27	1.70	23.2
16	26/0.254	1.49	0.41	2.31	14.6
14	41/0.254	1.87	0.41	2.70	8.96
12	65/0.254	2.36	0.60	3.56	5.64
10	66/0.32	3.00	0.60	4.20	3.55

Dongguan XSD Cable Technology Co., Ltd (subsidiary of Shenzhen Singder Insulation Materials Co., Ltd) is a Chinese professional manufacturer with "ISO9001, IATF16949, UL, cUL, CCC" approved in Dongguan city next to Shenzhen and Guangzhou.

★Main Products: UL/cUL AWM Wires&Cables, Automotive Wire, Industrial Wire, Hook-up&Lead Wire, Solar Cable(PV Wire), Heating Wire, FFC Wire, Flat Ribbon Cable, BV, RV, BVR, RVV, RVB, AVVR, RVVP, USB Cable, HDMI, DVI, VGA, Cable Assembly, Wire Harness and so on.

★Insulation Materials: PVC/PE/XLPE/LSZH/TEFLON/FEP/SILICONE RUBBER/TPU and so on.
