Product Description:
UL1185 Single Conductor Spiral Shielded Wire
① Rated temperature: 80ºC
② Rated voltage: 300V
③ Reference Standard: UL758, UL1581, C22.2 No.210
④ Passes UL VW-1 & CSA FT1 vertical flame test.
⑤ Uniform insulation thickness of wire to ensure easy stripping and cutting.
⑥ For internal wiring of electronic and electrical equipment and appliance, such as studios, sound systems, circuits and power adaptor for PC.
Technical Parameters:
| Conductor |
Insulation |
Spiral Shield |
Jacket |
Max. Cond Resistance at 20°C
(Ω/km) |
| AWG |
Construction
(No./mm) |
Diameter
(mm) |
Thickness
(mm) |
Diameter
(mm) |
Thickness
(mm) |
Diameter
(mm) |
Thickness
(mm) |
Diameter
(mm) |
| 28 |
7/0.127 |
0.38 |
0.43 |
1.24 |
38/0.1 |
1.44 |
0.45 |
2.34 |
239 |
| 26 |
7/0.16 |
0.48 |
0.43 |
1.34 |
45/0.1 |
1.54 |
0.45 |
2.44 |
150 |
| 24 |
11/0.16 |
0.61 |
0.43 |
1.47 |
46/0.1 |
1.67 |
0.46 |
2.58 |
94.2 |
| 22 |
17/0.16 |
0.76 |
0.43 |
1.62 |
54/0.1 |
1.82 |
0.46 |
2.74 |
59.4 |
| 20 |
26/0.16 |
0.94 |
0.43 |
1.80 |
56/0.1 |
2.00 |
0.46 |
2.92 |
36.7 |
| 18 |
41/0.16 |
1.18 |
0.43 |
2.04 |
64/0.1 |
2.24 |
0.46 |
3.16 |
23.2 |
| 16 |
26/0.254 |
1.49 |
0.43 |
2.36 |
74/0.1 |
2.56 |
0.46 |
3.48 |
14.6 |
