Black Ul2468 Flat Cable , Twin Wire Cable For Internal Wiring
1.Rated Voltage: 300V
2.Rated Temperature: 80ºC
3.Insulation Material: PVC
4.Conductor: Tinned or Bare, Stranded or Solid Copper
5.Pitch: 1.50mm, 2.00mm, 2.10mm or others
6.Reference Standard: UL758, UL1581, C22.2 No.210
7.Passes UL VW-1 & CSA FT1 vertical flame test.
8.Uniform insulation thickness of wire to ensure easy stripping and cutting.
9.For internal wiring of electronic and electrical equipment and appliance, computer, IDC connector, mainframe, speaker, lighting, electronics, wiring harness, etc.
Technical Parameters:
| Conductor |
Insulation |
Max. Cond. Resistance at 20°C
(Ω/km) |
| No. of Cores |
AWG |
Construction
(No./mm) |
Diameter
(mm) |
Thickness
(mm) |
Diameter
(mm) |
| 2 |
28 |
7/0.127 |
0.38 |
0.43 |
1.24X2.58 |
239 |
| 2 |
26 |
7/0.16 |
0.48 |
0.43 |
1.34X2.78 |
150 |
| 2 |
24 |
7/0.2 |
0.60 |
0.43 |
1.45X3.04 |
94.2 |
| 2 |
22 |
7/0.254 |
0.76 |
0.43 |
1.62x3.34 |
59.4 |
| 2 |
20 |
26/0.16 |
0.94 |
0.43 |
1.80X3.70 |
36.7 |
| 2 |
18 |
41/0.16 |
1.18 |
0.43 |
2.04X4.23 |
23.2 |
| 3 |
28 |
7/0.127 |
0.38 |
0.43 |
1.24X3.92 |
239 |
| 3 |
26 |
7/0.16 |
0.48 |
0.43 |
1.34X4.22 |
150 |
| 3 |
24 |
7/0.2 |
0.60 |
0.43 |
1.45X4.63 |
94.2 |
| 3 |
22 |
7/0.254 |
0.76 |
0.43 |
1.62X5.06 |
59.4 |
Packing and Shipping:
Packaging and Shipping of Customized Wire Cable
The customized wire cable will be packaged and shipped according to the customer’s instructions. For example, if the customer needs the wire cable to be delivered in bulk, it will be packaged in cardboard boxes, foam, or bubble wrap to ensure the safety of the product during transportation. If the customer requires the wire cable to be packaged more securely, an additional layer of plastic wrap or bubble wrap can be added.
The wire cables will be shipped to the customer using reliable shipping services such as UPS, FedEx, or DHL, depending on the customer’s delivery needs and preferences. The shipment will be tracked and monitored throughout the entire journey from the warehouse to the customer’s location.
FAQ:
- Q1: What is the Brand Name of the Customized Wire Cable?
- A1: The Brand Name of the Customized Wire Cable is XSD Cable.
- Q2: What is the Model Number of the Customized Wire Cable?
- A2: The Model Number of the Customized Wire Cable is Customized Wire Cable.
- Q3: Where is the Place of Origin of the Customized Wire Cable?
- A3: The Place of Origin of the Customized Wire Cable is Guangdong,China.
- Q4: What are the Certifications of the Customized Wire Cable?
- A4: The Certifications of the Customized Wire Cable are UL,CE,ISO:9001.
- Q5: How many sets of the Customized Wire Cable are required for the Minimum Order Quantity?
- A5: The Minimum Order Quantity of the Customized Wire Cable is 300sets.
